Characteristic impedance(Ω):

75

Operating frequency(MHz)

0-2000

Nominal Discharge Current (8/20μs) (In):

5KA

Voltage Protection Level( Up):

≤600V

Standing-wave ratio:

≤1.2

Transmission power:

200W

Insertion Loss (dB):

<0.2

Working Environment:

Temperature -40°C +70°C;

Relative humidity<95%;

Matching impedance(Ω):

75/93

Interface Model:

F head

Weight(kg) :

0.107
